Automatic Swing Doors Dubai & UAE

Automatic Swing Doors

Automatic swing doors provide hands-free access while retaining the familiar operation and compact footprint of a conventional hinged door. An automatic operator opens the door when activated and controls its closing movement, making swing automation particularly useful where a sliding entrance is impractical or an existing hinged door needs to be retained.

One of the biggest advantages of swing automation is retrofit flexibility. Many suitable existing aluminium, glass, timber and metal doors can be automated without rebuilding the complete entrance. This makes automatic swing operators popular for offices, hospitals, clinics, hotels, residential buildings, accessible entrances and controlled staff doors throughout the UAE.

AZTÖR provides a free site inspection before recommending an operator. We check the door width and weight, hinges or pivots, opening direction, structural fixing, available operator position, swing path, pedestrian traffic, wind exposure, electrical supply and the way the entrance is actually used. A powerful operator alone cannot compensate for a poorly aligned or mechanically unsuitable door.

Depending on the door geometry, automatic swing operators can use push-arm, pull-arm or compatible sliding-arm arrangements. Single and double doors can be automated, and suitable systems can coordinate two leaves where sequenced operation is required.

Activation can be completely hands-free or intentionally controlled. Radar sensors can provide automatic pedestrian activation, while touchless switches, push buttons, elbow switches and authorised access-control devices are useful where the door should open only when requested.

Safety is especially important because a swing door moves through an arc occupied by pedestrians. Depending on the application and selected system, safety sensors can monitor the swing path and doorway while opening and closing speeds, force and hold-open behaviour are configured around the entrance.

AZTÖR works with established automatic entrance manufacturers such as dormakaba, GEZE, ASSA ABLOY, TORMAX and other suitable brands available for UAE and GCC projects. The final operator is selected according to door dimensions, weight, usage, required arm arrangement, environmental conditions and project specification.

Existing automatic swing doors can also be repaired or modernised. AZTÖR diagnoses operator, arm, sensor, control-board, locking, activation and mechanical door problems before recommending component replacement or complete operator replacement.

AZTÖR provides automatic swing door installation, retrofit, repair and preventive maintenance across Dubai, Abu Dhabi, Sharjah, Ajman, Ras Al Khaimah, Fujairah and Umm Al Quwain, with suitable technical and project support available across the wider GCC.

Key Features

Single-leaf and double-leaf swing door automation
Suitable for new installations and retrofit projects
Automation of suitable existing manual doors
Overhead electromechanical swing operator
Push-arm configurations
Pull-arm configurations
Compatible sliding-arm arrangements
Radar sensor activation
Touchless switch activation
Push-button and elbow-switch operation
Swing-path and presence safety detection
Adjustable opening and closing behaviour
Programmable hold-open time
Automatic and manual operating options
Access control and biometric integration
Intercom and keypad integration
Electric locking integration where required
Battery backup options where specified
Coordinated operation for suitable double doors
Quiet operation for occupied environments
Preventive maintenance and breakdown repair

Technical Specification

Configuration	Single-leaf or double-leaf swing
Door Type	Glass, aluminium, timber or metal subject to compatibility
Drive System	Electromechanical automatic swing operator
Operator Position	Typically overhead mounted
Arm Arrangement	Push, pull or compatible sliding arm according to door geometry
Opening Direction	Inward or outward subject to entrance configuration
Activation	Radar, touchless switch, push button, elbow switch or access control
Safety	Presence and swing-path detection according to application
Operating Modes	Automatic, manual, hold-open or controlled modes depending on operator
Opening Angle	Configured according to door geometry and selected operator
Opening Speed	Adjustable within applicable operator and safety parameters
Closing Speed	Adjustable within applicable operator and safety parameters
Hold-Open Time	Programmable
Power Supply	Typically 220–240V AC, subject to selected operator
Locking	Compatible electric or electromechanical locking where required
Access Control	Card, biometric, keypad, intercom or compatible third-party system
Backup Operation	Battery or project-specific emergency operation where required
BMS Interface	Available where supported by the selected control system
Fire Alarm Interface	Project-specific interface where required and compatible
Leaf Capacity	Operator selected according to door width, weight and configuration
Installation	New installation, manual-door retrofit or operator replacement
Maintenance	Preventive maintenance, adjustment and corrective repair available

Automatic swing operators must be matched to the actual door rather than selected only by opening size. AZTÖR confirms the operator, arm arrangement, activation and safety package after a free site inspection covering door width and weight, hinges or pivots, opening direction, swing space, traffic and environmental conditions.

Typical Applications

Corporate office entrances
Commercial buildings
Hospitals and medical centres
Clinics and pharmacies
Accessible entrances
Hotels and resorts
Residential tower lobbies
Apartment common areas
Government buildings
Banks and financial institutions
Schools and universities
Retail stores
Restaurants and hospitality venues
Staff entrances
Controlled-access doors
Washroom entrances
Healthcare internal doors
Office reception areas
Existing manual door retrofit projects
Low and medium-traffic pedestrian entrances

Frequently Asked Questions

An automatic swing door uses a powered operator to open and control the closing of a conventional hinged door. It can be activated by sensors, switches or authorised access-control devices.

In many cases, yes. AZTÖR first checks the door condition, width, weight, hinges or pivots, structural fixing and available operator position before recommending a retrofit.

Yes. AZTÖR provides a free site inspection for applicable automatic swing door requirements to assess the existing door, structure, swing path, traffic, electrical supply and required controls.

Depending on the application, AZTÖR works with established manufacturers such as dormakaba, GEZE, ASSA ABLOY, TORMAX and other suitable automatic entrance brands available in the UAE and GCC.

A swing door rotates around hinges or pivots, while a sliding door moves horizontally. Swing automation is often more practical when an existing hinged entrance must be retained or there is insufficient side space for sliding leaves.

Yes, many doors constructed from these materials can be automated provided their dimensions, weight, hardware and structural condition are compatible with an appropriate swing operator.

Yes. Touchless switches are commonly used where opening should occur only when requested and physical contact with the activation device is undesirable.

Yes. Suitable radar or other activation sensors can provide hands-free opening where automatic approach detection is appropriate for the entrance.

Yes. Compatible operators can integrate with card readers, biometric readers, keypads, intercoms and other authorised access-control devices.

Yes. Suitable double-leaf doors can be automated, and compatible operators can coordinate the leaves where sequenced opening or closing is required.

Yes. Swing automation can make suitable entrances easier to use for wheelchair users and people with reduced mobility. The complete entrance design, clear opening and controls should be assessed against the project's accessibility requirements.

The required safety arrangement depends on the entrance and selected system. Because the leaf travels through a swing arc, sensor coverage and operating parameters need careful consideration.

Depending on the operator and project requirements, the door can have manual operation, battery backup or another specified emergency arrangement. The required behaviour is established during system selection.

Yes. AZTÖR can diagnose many existing systems regardless of the original installer, subject to equipment condition and availability of compatible replacement components.

Common problems include sensor faults, operator or control-board issues, damaged arms, locking problems, incorrect adjustment, worn mechanical door hardware and poor door alignment.

Yes. Maintenance can include operator inspection, arm and fixing checks, sensor testing, safety checks, door alignment, adjustments and fault identification according to the agreed AMC scope.

AZTÖR provides automatic swing door installation, retrofit, repair and maintenance across Dubai, Abu Dhabi, Sharjah, Ajman, Ras Al Khaimah, Fujairah and Umm Al Quwain, with suitable support across the wider GCC.
