Multi-Sensor Camera CCTV
Multi-Sensor Camera CCTV combines multiple imaging sensors within a single camera housing, allowing several directions or a much wider area to be monitored from one installation point.
AZTÖR Automation supplies, installs and maintains Multi-Sensor CCTV systems for warehouses, logistics centres, commercial buildings, shopping centres, parking areas, industrial facilities, campuses and large properties across the UAE.
Unlike a conventional single-lens camera, a Multi-Sensor Camera can use two, three, four or more imaging channels depending on the selected model. Each sensor can cover a different direction, helping reduce blind spots around building corners, intersections and large open areas.
Multi-Sensor Cameras are particularly effective where several conventional cameras would otherwise be installed close together. One properly positioned unit can simplify mounting, network infrastructure and overall camera layout while still providing multiple independent video views.
Depending on the model, individual sensors can offer adjustable viewing directions, different focal lengths, high-resolution imaging, WDR, low-light performance and AI analytics. The correct configuration is selected according to the site's required field of view and identification distances.
Panoramic Multi-Sensor Cameras can provide very wide or near-360° coverage, while multidirectional models can monitor separate areas simultaneously. These should not be confused with PTZ cameras: Multi-Sensor Cameras continuously view several directions, whereas a PTZ normally moves one viewing channel between different positions.
Suitable AI-enabled models can provide human and vehicle classification, intrusion detection, line-crossing and other analytics across supported channels. Advanced systems can also combine fixed panoramic sensors with an integrated PTZ channel for detailed event verification.
Multi-Sensor IP Cameras can integrate with compatible NVR and VMS platforms for independent channel recording, live monitoring, analytics and event management. Network bandwidth, recorder compatibility and storage must be sized for the combined video streams.
For UAE outdoor installations, AZTÖR considers heat, dust, humidity, sunlight, mounting height, vibration, environmental protection and maintenance access when selecting the camera and mounting arrangement.
AZTÖR provides new Multi-Sensor CCTV installation, camera replacement, NVR/VMS integration, system expansion, configuration, troubleshooting and preventive maintenance. Free site inspection is available across Dubai, Abu Dhabi, Sharjah, Ajman, Ras Al Khaimah, Fujairah and Umm Al Quwain, with suitable project support across the GCC.
Key Features
- Multiple Imaging Sensors
- Multi-Directional Surveillance
- Wide-Area CCTV Coverage
- 180° Panoramic Options
- 360° Panoramic Options
- Independent Camera Channels
- Adjustable Sensor Positioning
- Multiple Lens Options
- High-Resolution Imaging
- Wide Dynamic Range
- Low-Light Imaging
- Infrared Options
- AI Analytics Options
- Human & Vehicle Classification
- Intrusion Detection
- Line Crossing Detection
- Continuous Multi-Direction Monitoring
- Reduced Blind Spots
- Panoramic + PTZ Options
- NVR Integration
- VMS Integration
- ONVIF Support on Compatible Models
- PoE / PoE+ Options
- Edge Storage Options
- Remote Monitoring
- Control Room Integration
- Outdoor-Rated Models
- Installation & Configuration
- Repair, Maintenance & AMC
Technical Specification
| Camera Type | Multi-Sensor / Multi-Directional / Panoramic IP Camera |
|---|---|
| Number of Sensors | 2, 3, 4 or More, Model Specific |
| Image Sensor | CMOS, Model Specific |
| Resolution per Sensor | Model Specific |
| Total Camera Resolution | Combined Sensor Resolution, Model Specific |
| Lens Type | Fixed / Varifocal / Model Specific |
| Focal Length | Sensor & Application Specific |
| Sensor Position | Fixed or Adjustable, Model Specific |
| Coverage | Multi-Directional / 180° / 360° Options |
| Panoramic View | Available on Suitable Models |
| Independent Video Channels | Model Specific |
| Image Stitching | Available on Suitable Panoramic Models |
| PTZ Channel | Available on Selected Multi-Sensor Models |
| Wide Dynamic Range | Up to 120 dB+ on Suitable Models |
| Minimum Illumination | Model Specific |
| Day / Night | Available |
| IR Illumination | Available on Suitable Models |
| AI Analytics | Available on Suitable Models |
| Human Classification | Available on Suitable Models |
| Vehicle Classification | Available on Suitable Models |
| Intrusion Detection | Available on Suitable Models |
| Line Crossing | Available on Suitable Models |
| Video Compression | H.265 / H.265+ / H.264, Model Specific |
| Frame Rate | Resolution & Model Specific |
| Network Interface | RJ45 Ethernet |
| Network Bandwidth | Combined Stream Dependent |
| ONVIF | Available on Compatible Models |
| Recording | NVR / VMS |
| NVR Compatibility | Camera Channels & Recorder Specific |
| Edge Storage | microSD on Suitable Models |
| Power | PoE / PoE+ / Dedicated Power, Model Specific |
| Alarm I/O | Available on Suitable Models |
| Audio I/O | Model Specific |
| Outdoor Protection | IP66 / IP67 on Suitable Models |
| Impact Protection | IK Rating on Selected Models |
| Operating Temperature | Model Specific; UAE Outdoor Suitability to Be Verified |
| Mounting | Ceiling, Wall, Pole, Pendant or Application Specific |
| Remote Monitoring | NVR / VMS / Desktop / Mobile |
| Installation Type | New Installation, Replacement or CCTV Upgrade |
Multi-Sensor CCTV should be designed around coverage geometry rather than camera quantity alone. Sensor count, lens selection, mounting position, required identification distance, combined resolution, bandwidth and recording storage all affect system performance. NVR/VMS compatibility must also be checked because one physical Multi-Sensor Camera may generate multiple video streams or channels. AZTÖR Automation provides a free site inspection before final camera selection.
Typical Applications
- Warehouses
- Logistics Centres
- Distribution Centres
- Factories
- Industrial Facilities
- Commercial Buildings
- Shopping Centres
- Large Retail Stores
- Building Corners
- Building Perimeters
- Parking Areas
- Multi-Level Car Parks
- Large Entrances
- Open Yards
- Loading Areas
- Campuses
- Data Centres
- Transport Facilities
- Public Areas
- Control Room Surveillance
