Thermal Camera CCTV
Thermal Camera CCTV detects differences in thermal energy rather than relying only on visible light. This makes thermal surveillance particularly useful for perimeter security, industrial sites and locations where conventional cameras may struggle in complete darkness or difficult lighting conditions.
AZTÖR Automation supplies, installs and maintains Thermal CCTV systems for warehouses, factories, logistics yards, utilities, data centres, infrastructure sites, solar farms, industrial compounds and other high-security applications across the UAE.
Unlike a standard CCTV camera, a thermal camera creates an image from temperature differences within the scene. It can therefore detect people, vehicles and other heat-emitting objects without depending on conventional illumination.
For perimeter protection, suitable thermal cameras can provide human and vehicle classification, intrusion detection, line-crossing analytics and early-warning alarms. Detection capability depends on the thermal sensor, lens, analytics, target size and installation geometry.
Thermal cameras are available with different thermal resolutions and lens options. The correct lens is selected according to the required field of view and detection distance rather than simply choosing the highest available resolution.
For applications requiring both thermal detection and visual verification, bi-spectrum cameras can combine a thermal sensor with a conventional optical camera. This allows operators to detect an event thermally and then view additional visible-image detail where conditions permit.
Selected thermal systems can also support temperature measurement or thermographic applications. These functions require purpose-built radiometric equipment and should not be assumed for every thermal security camera.
Thermal cameras can integrate with NVR, VMS, alarms, perimeter protection and other compatible security platforms. Event-based integration can help control rooms focus on detected activity rather than continuously watching every camera.
For UAE outdoor installations, AZTÖR considers ambient temperature, direct sun exposure, dust, humidity, viewing distance, mounting stability, network infrastructure and environmental protection before final camera selection.
AZTÖR provides new Thermal CCTV installation, system integration, camera replacement, configuration, troubleshooting and preventive maintenance. Free site inspection is available across Dubai, Abu Dhabi, Sharjah, Ajman, Ras Al Khaimah, Fujairah and Umm Al Quwain, with suitable project support across the GCC.
Key Features
- Thermal Imaging CCTV
- Heat-Based Object Detection
- 24-Hour Perimeter Monitoring
- Complete Darkness Detection
- Human & Vehicle Classification
- Intrusion Detection
- Line Crossing Detection
- Perimeter Protection Analytics
- Long-Range Detection Options
- Thermal Sensor Technology
- Multiple Thermal Lens Options
- Bi-Spectrum Camera Options
- Thermal + Optical Imaging
- Temperature Measurement Options
- Radiometric Thermal Options
- AI Analytics on Suitable Models
- False Alarm Reduction Options
- NVR Integration
- VMS Integration
- Alarm Integration
- ONVIF Support on Compatible Models
- Remote Monitoring
- Control Room Integration
- Outdoor Thermal Cameras
- Fixed Thermal Camera Options
- Thermal PTZ Options
- Camera Replacement & Upgrades
- Installation & Configuration
- Repair, Maintenance & AMC
Technical Specification
| Camera Type | Fixed Thermal / Bi-Spectrum / Thermal PTZ |
|---|---|
| Thermal Sensor | Uncooled VOx Microbolometer or Model Specific |
| Thermal Resolution | 256×192, 384×288, 640×512 or Model Specific |
| Pixel Pitch | Typically 12 μm / 17 μm, Model Specific |
| Spectral Range | Typically Long-Wave Infrared, Model Specific |
| Thermal Sensitivity | NETD Model Specific |
| Thermal Lens | Fixed or Model Specific |
| Focal Length | Application & Detection Distance Specific |
| Field of View | Lens & Sensor Specific |
| Focus | Fixed / Motorised / Model Specific |
| Visible Optical Channel | Available on Bi-Spectrum Models |
| Optical Resolution | Model Specific |
| Day / Night Operation | Available |
| IR Illumination | Not Required for Thermal Imaging |
| Human Detection | Available on Suitable Models |
| Vehicle Detection | Available on Suitable Models |
| Intrusion Analytics | Available on Suitable Models |
| Line Crossing | Available on Suitable Models |
| AI Classification | Model Specific |
| Temperature Measurement | Available on Radiometric Models |
| Temperature Range | Model & Application Specific |
| Measurement Accuracy | Radiometric Model Specific |
| Video Compression | H.265 / H.264 or Model Specific |
| Frame Rate | Model Specific |
| Network Interface | RJ45 Ethernet on IP Models |
| ONVIF | Available on Compatible Models |
| Recording | NVR / VMS |
| Edge Storage | Available on Suitable Models |
| Alarm I/O | Available on Suitable Models |
| Audio I/O | Model Specific |
| Power | PoE / Dedicated Power / Model Specific |
| Outdoor Protection | IP66 / IP67 on Suitable Models |
| Operating Temperature | Model Specific; UAE Suitability to Be Verified |
| Mounting | Wall, Pole, Corner, Pendant or Application Specific |
| Surge Protection | Recommended for Outdoor Installations |
| Remote Monitoring | NVR / VMS / Desktop / Mobile |
| System Integration | CCTV, VMS, Alarm & Perimeter Security Systems |
| Installation Type | New Installation, Upgrade or Replacement |
Thermal CCTV should be designed around the required detection objective rather than camera resolution alone. Target size, required detection distance, thermal sensor resolution, lens focal length, mounting height and environmental conditions directly affect performance. Temperature measurement requires a suitable radiometric thermal camera and should not be confused with standard thermal security detection. AZTÖR Automation provides a free site inspection before final system selection.
Typical Applications
- Industrial Perimeters
- Warehouses
- Logistics Yards
- Factories
- Data Centres
- Utility Facilities
- Power Infrastructure
- Solar Farms
- Oil & Gas Facilities
- Critical Infrastructure
- Construction Sites
- Storage Yards
- Large Compounds
- Remote Sites
- Boundary Protection
- Parking Perimeters
- Ports & Marine Facilities
- Restricted Areas
- Control Rooms
- 24-Hour Perimeter Surveillance
